Seafood canning company Chicken of the Sea International is among the many companies responding to the multipack trend sweeping the grocery aisles. The California-based company, which in 2014 is celebrating its 100th anniversary as an American food icon, decided it needed to add a bundling machine that could shrink-wrap multiple cans into a package at its Lyons, GA, plant.
After reviewing the available options, Chicken of the Sea opted for the 597 Tritium multipacker with Robo-Wand™ wrapping module, and 296 Continuum tray shrink packers, manufactured in the U.S. by Standard-Knapp. The new equipment lets Chicken of the Sea adapt to the particular pack styles required by various customers. Now the company reports that its new packaging equipment has helped increase production on the line by 50% to 75%, while reducing machine downtime significantly.
Responding to new grocery trends
Chicken of the Sea, a provider of shelf-stable seafood, including tuna and salmon, opened a domestic canning operation in 2009 at a 200,000-sq-ft facility in Lyons. The plant employs 350 people and produces about 36,000 cases of product a day.
Over time, a larger and larger proportion of the product was being packaged into shrink-wrapped multipacks, in response to industry trends. The plant had originally outsourced that capability but eventually reached the point where it needed its own bundling machine to shrink-wrap a range of multipacks on a new high-speed packaging line it was installing. Indeed, as part of its centennial marketing program, Chicken of the Sea expects strong sales of its tuna four-packs, which are highlighting a $1 million giveaway to deserving nonprofits across the U.S.
As Jim Cox, Vice President of Operations for Chicken of the Sea, explains, “The industry has gone to multipacks in a big way, and we had to find a machine that could provide us what we needed to meet our customers’ needs, including the four-pack that has become popular in grocery stores, as well as six-, 10- and 12-packs.”
Cox was looking for a local source with equipment that was strong enough to do what he needed. He reviewed the options by attending PACK EXPO and talking to personal contacts in the close-knit tuna industry. After narrowing the options to three main contenders that were robust enough for his production line, he ultimately selected Standard-Knapp, a company known for supplying the first tray packers to the tuna canning industry in the 1980s. “I had already used one of the machines in the tuna canning industry and had done well with it, which reduced the risk of buying a machine that may or may not work.”
The equipment selected was the 597 Tritium multipacker with Robo-Wand wrapping module, and two traditional Continuum 296 tray shrink machines. Before making the decision, Cox visited a plant that had installed the Standard-Knapp equipment, along with Plant Engineering Manager Larry Hightower, PE, who is responsible for managing the plant’s capital projects and maintenance. They ran tests of Chicken of the Sea products and had the opportunity to see the equipment in action.
“Their equipment met both speed and cost requirements, is built for 24/7 operations, and is extremely strong,” notes Cox. What’s more, Cox liked the fact that the equipment is manufactured in the U.S with U.S. components, which he considers important, because he had dealt with both European and Asian packaging equipment in the past and found it difficult and expensive to get parts and service people. He also liked the fact that Standard-Knapp is an employee-owned company, with all its employees totally committed to putting out a quality product.
The Tritium gave Chicken of the Sea the versatility it needed. The modular construction easily allows for future expansion to the system and allows for fast, easy changeover. Each changepart is specifically designed for the particular product, and once installed, the operator simply selects the desired product from the HMI, and the now the machine is ready for production. The company now has the ability to feed the tray-pack machine directly, and it can run separately from the multipack. If they don’t need the multiple pack feature, they can now overwrap loose-packed cans.
According to Hightower, the ease of setup is one of the Tritium’s most important features. “The way the machine is designed makes it much easier to change over from one pack style to another and easier to change film from one type to another. In addition, the system automation and safety features are unique,” he says. With the Tritium, the machine is fully protected to ensure the safety of the operator.
Recovery is also much better, says Hightower. Since the equipment is servo-controlled, if something crashes, and there is a bad label or bad can, operators can clean and reset the machine, hit start, and the machine is up and running immediately. On the older-generation machines, the chain could jump, and the mechanic had to do a lot more to get the machine up and running again.
Hightower also calls attention to the high-speed Robo-Wand wrapping module, which can be fully customized to follow the height and length of the final pack pattern, providing a consistent, tight, wrinkle-free wrap. “The overwrap wand is held on by a magnet, and actually pops off if there is a crash,” he explains. “The film can fold over, and when it does, it can cause cans to fall over. If the wand is trying to overwrap and a can is in the way, the wand snaps off and keeps it from breaking or damaging other parts of the machine.”
One of the features that most impressed Cox was the slide-out film bed, which makes access and maintenance in the film cutting area much easier and quicker. With its slide-out film-bed drawer, maintenance is simple, and operators can quickly and easily recover from a jam. “Bundle packs are a pretty complex process, requiring the ability to change over sizes quickly, and add film safely and easily,” notes Cox. “A big part is ergonomics, because the rolls of film are so heavy, and the Tritium is equipped with a side film stand. Loading film is now safe and easy. In addition, it’s a modern machine that incorporates motors and programmable logic controllers, is equipped with proper safety stops, and gives the company everything we need to operate highly efficiently.”
Hightower agrees, noting that the film bed is an excellent quality, with sensors monitoring the film, ensuring it remains in the correct position, cuts consistently, and fully wraps all packs.
Another valued feature is the Zero-Gap II infeed, which uses electronic sensors to monitor and control product movement, maintaining a constant low line pressure and maximizing machine uptime. The new infeed allows for positive grouping and escapement of product. Smoothly and reliably, the infeed guarantees steady release of product, with no mispacks, tipping, or crashing.
Standard-Knapp also assisted Chicken of the Sea to integrate the total solution into their production line by developing drawings and a control scheme, and introducing them to Arrowhead Systems, Inc., a provider of conveyor, packaging machinery, and line productivity solutions. Arrowhead helped equip the line with the most appropriate conveyors and auto-stacking equipment, and integrated equipment controls. Says Hightower, “Standard-Knapp’s assistance with integrating all the components of our new line, combined with supplying these major machines, really helped get the project completed.”
Equipment increases production over 50%
According to Chicken of the Sea, the new equipment runs more constantly and is far steadier than any other tray packer in the plant, increasing overall line efficiency considerably. The Standard-Knapp equipment runs at efficiencies of over 95%, much higher than that of the other ancillary equipment required for the line, including stackers and palletizers. They estimate they are producing roughly 50% to 75% more product than was capable with their older machinery, all with a 20% manpower reduction on the line.
The new Tritium machine has the ability to run up to 120 trays/min and replaced a machine that was only running 20/min. Currently the machine is operating extremely well, with speeds of about 80 trays/min, so there is room for expansion in the future. In addition, downtime over the course of the week has dramatically decreased. More changes are planned, with Standard-Knapp recently converting the film bed on an older piece of equipment at the plant to the new style film bed.
“Standard-Knapp is extremely customer-oriented and responsive,” says Cox. “Whether we need an engineer, parts, or service, they go all out to solve the problem and follow up on every item they promised.” The company is also planning to add other new machines to expand in the future. “We love their customer service and will definitely continue to work with them as we expand our production and update our facility.”
