These fractional HP motors from Omega Engineering come in sizes from 1/3 to 2 H.P. and are available with a double reinforced welded 56H base or without a base in the round body style.
Construction
– Windings double dipped and cured in polyester insulating varnish
– Anti-rust coated rotor to protect against corrosion
– Double-lip shaft seals plus V-ring shaft slingers
– Internal bearing retainer
– Laser-etched full-fact name plates
– Watertight stainless cord connector pre-installed in the split designed conduit box.
Specifications
Voltage: 230/460V, 3 phase 60 Hz—can run on 50 Hz with reduced service factor of 1.0
Frame/Enclosure: 56C/TEFC, 300 grade stainless steel
Rated Speed: 1725/3460
Duty Cycle: Continuous
Base Type: C-face—rigid
Shaft: Keyed, 304 Stainless Steel
Bearings: 6205 DDU
Rotation: CW/CCW
