EXAIR’s Heavy Duty Line Vac is a compact and quiet powerful in-line conveyor that transports high volumes of material through ordinary hose or tube. Commonly used to transfer complex shapes, bulk solids and waste, the units feature large throat diameters that make it possible to convey more material over long vertical and horizontal lengths. The conveying rate of this heavy duty conveyor is typically twice that of ordinary air powered conveyors.
Heavy Duty Line Vac ejects a small amount of compressed air through directed nozzles into the throat to produce a vacuum on one end and high output flows on the other. Response is instantaneous. The material conveying rate is easily controlled with a pressure regulator. An optional bracket permits easy mounting. No moving parts or electricity assures maintenance free operation.
Designed for rugged, industrial applications, Heavy Duty Line Vac has a hardened alloy construction that helps prevent premature wear. Seven sizes up to 3″ (76mm) are available that fit popular hose and tube diameters. Applications include part transfer, hopper loading, material conveying, waste/trim removal, fiber tensioning, chip removal and filling operations.
