This content was written and submitted by the supplier. It has only been modified to comply with this publication’s space and style.
Roll Diameter: 24" 610 mm
Paper Basis Weight: 20-80 lbs. 30-118 g/m2
Unwind Film: All grades
Emergency Stop: 300 fpm/sec
1.6 m/s2
Core Diameter: 3" 76 mm
5" 127 mm
6" 152 mm
Programmable Web Tension: 10-30 lbs.
Air Consumption: Max. 4SCFM @ 80 PSI during splice 120 L/min @ 5.6 bar
Power Consumption: 2 KVA max.
Standard Electrical Specifications (other configurations are availible at extra cost): 230 ± 10% V.A.C. 3 Ph., 60 Hz
460 ± 10% V.A.C. 3 Ph., 60 Hz
380 ± 10% V.A.C. 3 Ph., 50 Hz
Standard Features:
Microprocessor Based Controls
Automatic Splice Actuation
Rolling Nip Splice Head
Cantilevered shafts for direct roll loading
Solid formed steel frame
Manual roll sidelay adjust ± 1"
Pneumatic disk brakes
Nested festoon
Venturi vacuum system
Options:
500 fpm splicing speed
Angle bars
Vacuum blower
Register splice
Heat seal splicing head
CE Compliance application
Splice imminent output
Splice occured output
