Secondary Packaging

Loading and filling module

Universal Loading and Filling Module ULF features both top- and side-loading of pillow-style bags into RSCs. Suitable for companies requiring different case packing styles and configurations.

December 31, 2002

Case/Tray Packing: Page 84

Secondary Packaging

Label applicator

The 3M-Matic Side/Top Label Applicator SA2000 prints crisp images with variable information using Scotch® Printable Label Tape, then accurately applies it to the side or top of a shipping carton.

December 31, 2002

Secondary Packaging

Gray & Company: Case loading for candy producer

Two cases are indexed into position and are pneumatically tilted away from the robot to facilitate loading. After the cases are half filled by the Wexxar machine, with 16-oz cartons, a corrugated divider is inserted before additional rows are loaded to complete the cases. The robot picks and places these cartons at a rate of 60/min.

November 30, 2002

Conveying & accumulation

Gray & Company: Case sealing at candy manufacturer

Cases are discharged from the loader to the Wexxar Model WSH-06 case sealer. The filled cases discharge from the robot and round a short conveyor section to the sealer.

November 30, 2002

Cartoning

Janes Family Foods: Right-angle setup for case sealing

At Janes’ Concord, Ontario, Canada plant, this carton sealer from Bradma-Lake is set up on a right angle to save space. The top flap is closed and sealed with hot melt adhesive dispensed by a Nordson hot-melt system as the carton conveys along the first conveyor “leg.” At the end of this leg, a stationary bar pushes the carton 90° along the second leg to seal the carton’s sides.

November 30, 2002

Secondary Packaging

Golden State Vintners: Case packing of wine bottles

Model Flex 835 case packer from Hartness (Greenville, SC). It's preceded by a Hartness three-lane infeed section that relies on sensors to signal a gating device which lanes are in need of bottles.

November 30, 2002

Secondary Packaging

Case erector/bottom sealer

SWF Companies (Altamonte Springs, FL) has redesigned the CE 151 high-speed, automatic case erector/bottom flap sealer. Reaching speeds to 45 cases/min, the CE 151’s standard features include a Nordson hot melt system, easy load hopper, and multiple case size capabilities.

November 30, 2002

Secondary Packaging

Ergonomics guides give packaging a lift

New voluntary guidelines from OSHA should give packaging departments added leverage with upper management.

November 30, 2002

Labeling

Labeler and tray packer meet for the first time

Janssen Pharmaceutical, Beerse, Belgium, has installed a high-speed labeler that automatically feeds product into a tray packer without any need for manual handling between the two packaging operations. According to the company, this integration is the first of its kind in Europe.

November 30, 2002

Secondary Packaging

Pack Expo video coverage: High-speed case/tray packer for drink pouches

BluePrint Automation (Colonial Heights, VA) demonstrated a servo-driven, robotic top-loading machine packing stand-up drink pouches into a corrugated display case at speeds of about 450 pouches/min, though the manufacturer says the machine can reach speeds to 500 pouches/min. Applications include liquid drink pouches and retortable pouches such as pet food. Accommodates multiple pack sizes, product sizes, and carton configurations. Manufacturer claims no changeover is required between varying products or pack configurations.

October 31, 2002

Flexible packaging

Video coverage of Pack Expo 2002

NEWS FROM PACK EXPO: Packaging World Editors shot video footage of eight packaging machines on the show floor. See video clips

October 31, 2002

Flexible packaging

Pack Expo Video: High-speed case/tray packer for drink pouches

NEWS FROM PACK EXPO: BluePrint Automation (Colonial Heights, VA) demonstrated a servo-driven, robotic top-loading machine for case-packing stand-up pouches. See video clip of this machine

October 31, 2002

Secondary Packaging

AS-i-Safe machine safety network

NEWS FROM PACK EXPO: Pearson Packaging (Spokane, WA) displayed its R235 case erector and bottom sealer equipped with AS-i-Safe technology from Siemens Energy & Automation (Alpharetta, GA).

October 31, 2002
