Carlo Gavazzi: Three-phase monitoring relays

Optimizing panel space is a primary goal for most manufacturers. Thanks to the low profile DIN housing and 17.5mm width, it is possible to install these monitoring relays in industrial cabinets as well as in electrical distribution NORM panels. With a built-in switch mode power supply, DPA52 and DPB52 have the added advantage of filtering and minimizing harmonic distortions, which can help prevent devices from overheating and most of all prevent failures and false alarms which could lead to unexpected machine downtime.

The DPA52 and DPB52 come with features that offer versatility and ease of use, including wide input voltage range, multi-color LED indicators for visual status, and a relay contact output. They conform to global standards such as UL 508, CSA C22.2 and EN 60947-5-1, and can be used globally in applications/markets where it is necessary to monitor phase presence, sequence, and value, such as HVAC, Lifts and Escalators, Material Handling, Water Treatment, and others.

Features include:

• 125 VLL to 624 VLL (208vV -40% to 480 V +30%)
• Operating frequency from 45 to 65Hz
• 17.5mm wide - DIN rail mounting (1 DIN Module for NORM panels)
• Screw terminals
• Alarm LED with type of alarm indication
• Switch mode power supply
